01 Introduction
Before producing films using equipment such as cast extruders or stretching machines, a specific control protocol involving heating and temperature-holding phases is required—along with the mandatory recording of these steps. But is this truly necessary? Today, the editor will discuss the significance of this control protocol from three key perspectives: equipment, raw materials, and product performance.
02 First: Protecting the Equipment
As we all know, the core heating components of extrusion and stretching equipment—such as barrels, die heads, and stretching rollers—are typically large metal structures embedded with precision heating elements and sensors. In actual production processes, the implementation of a controlled heating and temperature-holding protocol offers several distinct advantages:
(1) Prevention of Thermal Shock and Thermal Stress Damage:
Thermal Shock: If the heating rate is too rapid, significant temperature differentials can arise between the inner and outer layers of metal components, as well as between areas of varying thickness. Due to differential rates of thermal expansion and contraction, immense internal thermal stresses are generated.
Consequences: In mild cases, this stress can cause micro-deformation in precision components (such as die lips), thereby compromising the uniformity of the material output. In severe cases, it can lead to cracks or even catastrophic fractures in large cast-aluminum heaters or barrel liners, resulting in costly equipment damage. The temperature-holding phase (e.g., maintaining a specific temperature—such as 100°C—for a set duration after heating) is designed to allow heat to permeate fully and uniformly throughout the entire component, thereby eliminating internal temperature gradients and ensuring the equipment enters operational mode in a uniform and stable state.
(2) Protection of Precision Heating and Temperature Control Systems:
Modern equipment often employs zone-based temperature control (where a single die head may feature dozens of independent temperature zones). Rapid heating demands that the heating elements output massive amounts of power within a very short timeframe; this places immense strain on the power grid, solid-state relays, and the heating rods themselves, increasing the risk of overload, electrical breakdown, or premature component failure.
A strictly controlled, phased heating protocol ensures that heating power is released gradually and smoothly, thereby serving as a protective measure for the entire electrical system.
(3) Ensuring the Accuracy of Measurement and Control:
A thermocouple measures the temperature specifically at its point of installation, rather than the temperature of the entire metal mass. The purpose of the temperature-holding phase following the initial heating is to ensure that the temperature reading obtained by the thermocouple accurately represents the overall average temperature of the entire controlled zone. Without this step, the control system would receive a "false signal," leading to subsequent inaccuracies and deviations in process control.
03 Secondly, the purpose is to properly process the plastic raw materials.
The second aspect of this analysis approaches the subject from the perspective of polymer material processing—which constitutes the fundamental rationale behind the existence of the heating/holding temperature program. This is because the processing of polymer materials (such as PP, PE, PET, PA, etc.) is a comprehensive process involving both thermodynamics and rheology.
(1) Analyzing the role of temperature holding in terms of phase transition and melt uniformity: Solid-state resins (particularly crystalline polymers like PET and BOPP) require the absorption of sufficient heat (specifically, the enthalpy of fusion) to transition from a crystalline state into a uniform melt. If the material is heated too rapidly—bypassing its melting point too quickly—it can lead to a "sandwich" phenomenon where the outer layers have melted while the inner core remains in a solid state. The function of temperature holding: By maintaining an appropriate holding temperature (or applying a slow heating rate) as the material approaches and passes through its melting range, sufficient time is allowed for heat conduction. This ensures that the resin granules are heated uniformly—both internally and externally—and undergo complete melting. This step serves as a prerequisite for obtaining a melt characterized by uniform viscosity and an absence of unmelted crystalline particles. A non-uniform melt will inevitably lead to the formation of film-breaking points or optical defects during subsequent stretching processes.
(2) Eliminating residual stress and "thermal history" effects: During the synthesis, granulation, transportation, and storage of resins, specific internal stresses and crystalline morphologies inevitably develop within the material. Rapid, non-equilibrium heating can effectively "lock in" or "amplify" these inherent defects within the resulting melt. The role of the programmed heating/holding cycle: Acting much like an "annealing" process, this cycle provides the polymer chain segments with sufficient time to undergo relaxation, thereby eliminating historical stresses and allowing the material to enter the molding stage in a more "pure" and relaxed state. This is absolutely critical for the production of high-performance optical films (such as protective films for polarizers or diffusion films).
(3) Controlling degradation and thermal history: Polymers are susceptible to degradation (e.g., via thermal oxidation or hydrolysis) if they remain at high temperatures for excessive periods. However, the heating phase itself poses a distinct risk; because solid-state resins exhibit poor thermal conductivity at lower temperatures, localized overheating can occur, potentially triggering the onset of degradation. The significance of a scientifically designed program: An optimized heating/holding program ensures complete melting while simultaneously minimizing the total residence time of the material within the high-temperature zone, thereby allowing for precise control over its "thermal history." This level of control is particularly crucial when processing heat-sensitive materials (such as certain bio-based plastics or PA) and when utilizing recycled materials.
04 Ultimately, It’s About the Product
Heating and temperature-holding control programs exert a significant influence on product performance, primarily manifesting in the following aspects:
(1) Thickness and Appearance Uniformity
A uniform melt is the fundamental prerequisite for uniform film thickness (both in the transverse and longitudinal directions). Any viscosity fluctuations resulting from uneven heating will lead to non-uniform melt discharge at the die exit; these irregularities are subsequently amplified during the stretching process, resulting in irreversible thickness tolerances.
(2) Crystallization and Orientation Control
Prior to longitudinal and transverse stretching, the cast sheet or film web must be maintained in a precise and uniform thermal state. This temperature is typically set within a narrow window—specifically, above the polymer's glass transition temperature (Tg) but below its crystallization onset temperature.
The Role of the Program: A rigorous heating program ensures an extremely uniform temperature distribution across the entire cast sheet or film web. Only under such conditions can the orientation of molecular chains during stretching (which determines strength and modulus) and the crystallization during subsequent heat setting (which determines thermal stability and shrinkage rate) be uniform and controllable. Non-uniform temperatures can lead to localized over-stretching (increasing the risk of film breakage) or under-stretching (resulting in substandard performance), as well as issues in the final film such as uneven shrinkage and warping.
(3) Optical Properties
A film's haze and light transmittance are directly correlated with the size and uniformity of its internal crystallites. A controlled and gentle thermal process facilitates the formation of a fine, uniform crystalline structure, thereby yielding superior optical properties. Rapid or uneven heating, conversely, can lead to the formation of large spherulites, causing the film to appear hazy.
(4) Surface Properties and Post-Processing Suitability
Uniform thermal treatment helps establish a stable surface morphology and interfacial tension. This stability is critical for achieving optimal adhesion in downstream processes such as corona treatment, coating, and lamination.
05 Summary
Simply put, a rigorous heating and holding protocol serves to provide the equipment and materials with a period for "warming up" and "preparation." For the equipment, this prevents damage and stabilizes operating conditions. For the raw materials, it ensures uniform melting and eliminates "material memory." For the final product, it lays a solid foundation and enables precise control over ultimate performance characteristics. This constitutes not merely a standard operating procedure, but rather the embodiment of core wisdom derived from the convergence of materials science and process engineering expertise. Without this precise "prelude," all subsequent high-speed and high-precision extrusion and stretching processes would be impossible to execute stably—let alone yield film products of high performance and exceptional consistency.
